Tesla Model 3 Wheels and Rims

Tesla Model 3 Aftermarket Wheel Fitment

The Tesla Model 3 has been on one platform since 2017, with a 2026 Highland refresh that kept the same bolt pattern. Every Model 3 uses 5x114.3 (also called 5x4.5). Where the Model 3 splits is at the trim. The Non-Performance trims (Standard Range, Long Range RWD and Long Range AWD on certain years) ride on a clean 64.1mm wheel-face hub bore. The Performance ships with a stepped hub: a 64.1mm inner hub face stepped out to a 70.1mm outer ring. The customer-relevant rule: a Performance fits wheels with EITHER a 64.1mm OR a 70.1mm centerbore. Bores between those two values do not fit cleanly. Pick your trim below and the fitment specs follow. The Model Y sibling platform lives at /wheels/tesla/model-y.

Find Your Tesla Model 3 Trim

Pick your trim to see wheels and rims that fit your specific Model 3. Bolt pattern stays 5x114.3 across the lineup. What changes are the hub design, the brake clearance, and the factory wheel size. The Non-Performance trims use a clean 64.1mm wheel-face hub bore. The Performance uses a stepped hub (64.1mm inner / 70.1mm outer), so it accepts wheels bored to either of those two centerbores and a tighter aftermarket offset window because of the larger brake package.

The Tesla Model 3 Bolt Pattern

Every Tesla Model 3 uses 5x114.3 (also called 5x4.5, because 114.3mm equals 4.5 inches). That covers the Non-Performance trims (Standard Range, Long Range RWD, Long Range AWD on certain years), the Performance, and the 2026 Highland refresh. The wheel face hub bore is 64.1mm on the Non-Performance trims. The Performance carries a stepped hub: a 64.1mm inner face and a 70.1mm outer ring.

5x114.3 is a common Japanese-pattern bolt spacing, but the Model 3 hub bore (64.1mm on Non-Performance, 64.1/70.1mm stepped on Performance) is smaller than the typical Japanese 66.1mm bore. That means a Honda or Toyota wheel with a 66.1mm bore will not be hub-centric on a Non-Performance Model 3 without a centering ring. The pattern also matches the Model Y, but offset and width windows differ between the two platforms because the Model Y is the taller SUV body, and the Model Y hub is a clean 64.1mm bore on every trim, not the Model 3 Performance stepped design. Compare against the rest of the Tesla lineup at our Tesla wheels and rims hub.

Tesla Model 3 Performance Stepped Hub

The Performance trim ships with a stepped hub design that the Non-Performance trims do not carry. The hub geometry, measured directly on a customer Performance: a 64.1mm inner hub face stepped out to a 70.1mm outer ring. The step ring itself is roughly 13mm wide, 2.25mm thick at the outer step, and 3.00mm at the inner step.

The customer-relevant rule for buying a wheel: a wheel with a 64.1mm centerbore sits hub-centric on the inner core, and a wheel with a 70.1mm centerbore clears the inner core and rides hub-centric on the outer step. Centerbores between 64.1mm and 70.1mm do not fit cleanly. They are too large for the inner hub and too small for the outer step. On the Non-Performance Model 3, the rule is simpler: a 64.1mm centerbore (or a larger bore brought back to 64.1mm with a hub-centric ring) seats on the wheel face. If your fitment needs rings or a sized bore, they'll be included with the order.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Tesla Model 3 Wheels

Element Wheels measures fitment on the Model 3 directly, both Non-Performance and Performance trims. For the Model 3 that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height on the Performance, hub geometry measurement on the Performance stepped hub (where we captured the 64.1mm inner face / 70.1mm outer step ring directly on a customer car), lug stud height, and turning clearance with the wheel and tire installed. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

That measurement work is what produced the trim-specific fitment windows on this page, and it is the reason we can publish the Performance stepped-hub dimensions with the confidence to back them with the Fitment Guarantee.

Tesla Model 3 Wheels and Rims FAQ

Get Tesla Model 3 Wheels Right the First Time

Pick your trim above to see wheels and rims that fit. We measure on the Model 3 platform on both Non-Performance and Performance trims, verify hub geometry on Performance variants before shipping, and tune the offset window per trim. Find your fit and start enjoying your build sooner.
