Cadillac DeVille Wheels and Rims

Cadillac DeVille Aftermarket Wheel Fitment

The Cadillac DeVille is the full-size luxury sedan Cadillac sold for the 1994 through the 2005 model year on the GM Premium FWD front-drive platform. It is the modern Northstar V8 generation of the DeVille name, covering the 1994-1999 DeVille Sedan, Concours, and d'Elegance trims and the 2000-2005 generation that introduced the DHS and DTS sub-trims on the DeVille body. The standalone DTS model that replaced the DeVille for the 2006 model year is a different car on the same platform. The DTS sub-trim on the 2000-2005 DeVille body is part of the DeVille line. Element Wheels carries the DeVille in one catalog row covering the full 1994-2005 production run. Every modern DeVille runs 5x115 with a 70.3mm hub bore. Five lugs, M12x1.5 thread pitch, factory lug nuts. The platform is one of the simplest Cadillac chassis we measure, and the same fitment hardware carries through the lineage to the 2006-2011 standalone DTS.

Find Your Cadillac DeVille Configuration

The modern Cadillac DeVille is one catalog row in our system: the 1994-2005 DeVille on the GM Premium FWD platform. Pick the generation to see wheels and rims that fit. Bolt pattern, hub bore, lug count, and thread pitch are identical across the full production run.

The Cadillac DeVille Bolt Pattern is 5x115

Every 1994-2005 Cadillac DeVille runs 5x115 with a 70.3mm hub bore. Five lugs, M12x1.5 thread pitch, factory lug nuts. The bolt pattern, hub bore, and lug hardware are the same across the 1994-1999 DeVille Sedan, Concours, and d'Elegance trims and the 2000-2005 DHS and DTS sub-trims. The trims change interior content, suspension tuning, and trim level. The wheel fitment hardware does not.

The Cadillac DeVille is 5x115 specifically. The 5x4.5 imperial nickname refers to 5x114.3 alone (114.3mm converts to 4.5 inches), not 5x115. The two patterns look similar on paper and a 5x114.3 wheel will technically thread onto 5x115 studs if the lugs are forced, but the stud spacing is off by 0.7mm at each lug position. That puts cumulative stress on the studs and is not safe on a full-size luxury sedan. Confirm 5x115 before you order.

The 70.3mm hub bore is the GM Premium FWD hub spec that carried across the DeVille from 1994 through 2005 and into the standalone DTS model from 2006 through 2011. If your aftermarket wheel has a centerbore larger than 70.3mm (common on universal-fit wheels and on wheels originally specced for a different platform), it needs a hub centric ring to land hub-centric on the DeVille hub.

Compare across the rest of the Cadillac lineup at our Cadillac wheels and rims hub. The standalone DTS that succeeded the DeVille runs the same 5x115 / 70.3mm fitment hardware, so DeVille wheels and DTS wheels cross between the two cars.

Wheel Window on the Cadillac DeVille

The Element measured diameter window on the DeVille runs 16 to 20 inch. Width runs 7 to 9 inch on both axles. The catalog tags the DeVille as non-staggered (FT=1), meaning a square setup all four corners is the right approach. The DeVille is a front-drive luxury sedan first and a comfortable cruiser by design, and the rear axle does not carry a wider-tire performance role.

Trims across the 1994-2005 production run (Sedan, Concours, d'Elegance, DHS, DTS sub-trim) share the same brake package class for fitment purposes (catalog brake size 1/1, standard front and rear). Wheel size selection is the same across the trim line. The 2000-2005 DTS sub-trim on the DeVille body is the firmer-suspension trim, but it does not change the bolt pattern, hub bore, or wheel window. Note that the standalone DTS model from 2006 onward is a separate car, also covered by us at /wheels/cadillac/dts and also 5x115 / 70.3mm.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Cadillac DeVille Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including the modern DeVille line. For the DeVille that means clearance from the wheel to the fender on both axles, gap between the back of the wheel and the front strut tower (the front-drive layout puts the strut tower close to the inner barrel), front brake caliper height across the trim variants, hub bore confirmation to the 70.3mm Premium FWD spec, lug seat geometry across the M12x1.5 thread pitch, and turning clearance with the wheel and tire installed at full lock. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do. That measurement work is what produces the published 16 to 20 inch diameter window and the 7 to 9 inch width window above.

Cadillac DeVille Wheels and Rims FAQ

Get Cadillac DeVille Wheels Right the First Time

Click through to your DeVille fitment above to see wheels and rims that fit. We measure on the DeVille across the full 1994-2005 production run, confirm the 5x115 / 70.3mm fitment hardware, and verify diameter and width windows on the platform. Find your fit and start enjoying your build sooner.
