Chevrolet Silverado 3500 Wheels and Rims

Chevrolet Silverado 3500 Aftermarket Wheel Fitment

The Chevrolet Silverado 3500 is Chevy's one-ton heavy-duty pickup and the workhorse end of the GM HD truck lineup. The 3500 splits into two configurations that share the same chassis but run different rear axles. Single-rear-wheel (SRW) 3500 trucks share running gear and the bolt pattern with the Silverado 2500 in our catalog: 8x165.1 on 1999-2010 trucks and 8x180 on 2011 and newer. The 3500 Dually (DRW) carries the same front-axle pattern but the rear axle is a different spec to accommodate four rear tires on a single axle: 8x165.1 / 116.7mm CB on 1999-2010 duallys and a wider 8x210 / 154.2mm CB on 2011 and newer duallys. Element Wheels tracks stock height, leveled, and 4-inch, 6-inch, and 8-inch lift fitments separately on the SRW trucks, with 33-inch, 35-inch, and 37-inch tire options at each lift. The Dually runs its own fitment window with narrower rear-wheel widths in the 6-9 inch range because the dual-tire setup carries the load on two tires per side rather than one. Find your configuration below.

Find Your Chevrolet Silverado 3500 Generation

Pick your year range and rear-axle configuration to see wheels and rims that fit your specific Silverado 3500. The SRW bolt pattern transitions at 2011 from 8x165.1 to 8x180. The 3500 Dually rear axle also transitions at 2011, from 8x165.1 to a wider 8x210 / 154.2mm CB spec. Every generation has stock-height, leveled, and multiple lifted fitments in our catalog.

The Chevrolet Silverado 3500 Bolt Pattern

On the single-rear-wheel Silverado 3500, the bolt pattern follows the same GM HD transition as the Silverado 2500. The 1999-2010 SRW 3500 (GMT800 and GMT900 platforms) ran 8x165.1 with a 116.7mm hub bore. The imperial nickname for that pattern is 8x6.5 (165.1mm = 6.5 inches). In 2011, GM moved the HD lineup to a new chassis (the GMT K2HD) with a wider 8x180 pattern and a 124.1mm hub bore. The 8x180 pattern has stayed on the SRW 3500 through the 2015-2019 refresh and the 2020-and-up current generation. Both eras carry 8 studs on the SRW trucks, so lug count alone will not distinguish the two; the year is the deciding factor. Pre-2011 = 8x165.1. 2011 and newer = 8x180. The wheels do not bolt across that transition.

The 3500 Dually has its own rear-axle geometry to accommodate four rear tires on a single axle. On 1999-2010 duallys, the rear axle stayed on 8x165.1 / 116.7mm CB (same as the SRW trucks of that era). From 2011 onward, the Dually rear axle moved to 8x210 / 154.2mm CB, a wider 8-lug pattern designed specifically for dual-tire geometry. The front axle on the 3500 Dually shares the SRW pattern of the same era: 8x165.1 on 1999-2010 duallys, 8x180 on 2011 and newer duallys. Rear-wheel widths on the 3500 Dually are narrower (6-9 inch range) because the dual-tire setup carries the load on two tires per side. Dually rear wheels do not fit anywhere else; the 8x210 rear-axle pattern is a Dually-only spec.

The Silverado 3500 single-rear-wheel shares the Silverado 2500 SRW chassis and bolt pattern in our catalog (8x165.1 on 1999-2010, 8x180 on 2011 and up). A 2500 wheel of the same era will bolt to a 3500 SRW. See the Silverado 2500 wheels and rims hub for the lighter HD sibling. The half-ton Silverado 1500 uses a 6-lug 6x139.7 pattern instead and is covered on its own page; see the Silverado 1500 wheels and rims hub for the half-ton fitment. Compare across the rest of the Chevy lineup at our Chevrolet wheels and rims hub.

Why SRW, Dually, and Lift Status Each Have Their Own Fitment

The Silverado 3500 has an aftermarket buyer base that splits into roughly five groups. Stock-height SRW owners running 20 to 26 inch wheels on factory tire sizing for work or street use. Leveled SRW owners running a 2 to 3 inch front lift with 33-inch tires to even out the factory rake. Moderately lifted SRW owners running 4 to 5 inch lifts with 35-inch tires. Heavily lifted SRW owners running 6 to 8 inch lifts with 35 or 37 inch tires. And 3500 Dually owners, who run a separate rear-wheel geometry on every fitment because the dual-tire setup is its own specification. Element measures each of these cases separately on every generation. The wheel that fits a stock-height SRW 3500 can rub a fender or hit a control arm once the truck is lifted, and the Dually rear wheels do not interchange with anything else in the lineup.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Chevrolet Silverado 3500 Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including every Silverado 3500 generation back to 1999 and both SRW and Dually configurations. For the 3500 that means clearance from the wheel to the fender on stock and at every lift height we track, gap between the back of the wheel and the suspension, brake caliper height, hub protrusion, lug seat depth, tire clearance at the rear of the front wheel well on lifted trucks running 35-inch and 37-inch tires, and on the Dually the inner-tire to outer-tire spacing on the rear axle. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

Chevrolet Silverado 3500 Wheels and Rims FAQ

Get Chevrolet Silverado 3500 Wheels Right the First Time

Pick your generation and configuration above to see wheels and rims that fit. We measure on the Silverado 3500 platform across every generation and both SRW and Dually rear-axle setups, separate stock height from leveled and every lift height, and track 33-inch, 35-inch, and 37-inch tire fitments. Find your fit and start enjoying your build sooner.
