Fiat 500 Wheels and Rims

Fiat 500 Aftermarket Wheel Fitment

The modern Fiat 500 is the iconic compact city car Fiat revived for the global market in 2007. Element Wheels measures the Fiat 500 across the gasoline 500 and 500C convertible (2012-2019 in NA), the Abarth performance variant of the same chassis (2012-2019), and the all-electric 500e (2024 and up, the current production car). Every 4-lug Fiat 500 in our catalog uses 4x98 with a 58.1mm hub bore and M12x1.25 lug bolts. The 4-lug pattern is unusual on modern vehicles outside the small-car segment, and the 58.1mm hub bore is a Fiat small-car spec not shared with any common American or VW platform. The 500X compact crossover is a different platform (5x110, 65.1mm hub bore) and is not in scope for this hub. Pick your generation and variant below for the fitment specs that apply to your specific 500.

Find Your Fiat 500 Generation

Pick your variant to see wheels and rims that fit your specific 500. Bolt pattern is 4x98 with a 58.1mm hub bore on every 4-lug Fiat 500 we track. Lug bolts are M12x1.25. The standard 500 and 500C convertible share fitment. The Abarth shares fitment with the standard car. The all-electric 500e (2024 and up) carries the same 4x98 / 58.1mm hub spec forward as the current production Fiat 500.

The Fiat 500 Bolt Pattern: 4x98 and Why It Matters

Every 4-lug Fiat 500 in our catalog uses 4x98 with a 58.1mm hub bore and M12x1.25 lug bolts. The 4x98 pattern is a Fiat small-car standard shared with other Fiat compacts (Panda, Punto) and historically with some older Lancia cars. It is NOT 4x100, even though the two patterns look identical to the eye. The 2mm difference between 4x98 and 4x100 is real and matters. A 4x100 wheel sometimes appears to bolt onto a 4x98 hub at three of the four lug holes while binding on the fourth, which is the most common Fiat 500 fitment mistake we see. Do not run a 4x100 wheel on a 4x98 Fiat. The studs and lug holes will not align cleanly and the wheel will not seat flush against the hub face. Count your lug holes and verify the pattern as exactly 4x98 before ordering.

The 58.1mm hub bore is a Fiat small-car spec not shared with VW Group, BMW, Honda, Toyota, or any common American hub. A Fiat 500 wheel does not cross to any of those platforms even when the bolt count happens to match. Lug bolts on the 500 are M12x1.25, smaller than the M12x1.5 spec used on most Asian small cars and meaningfully smaller than the M14x1.5 spec used on the modern VW lineup. Use M12x1.25 conical-seat lug bolts only.

The 500X compact crossover (offered in NA 2016-2023) is a different platform entirely. The 500X uses 5x110 with a 65.1mm hub bore and is not interchangeable with the 4-lug 500. The 500X has its own model page and is not covered by this hub. Compare across the rest of the Fiat lineup at our Fiat wheels and rims hub.

Why the Abarth, 500C, and 500e Share the Same Fiat 500 Fitment Box

The Fiat 500 (2012-2019) and the 500C convertible (2012-2019) share the same chassis, the same 4x98 / 58.1mm hub spec, the same M12x1.25 lug bolts, and the same aftermarket wheel window. The 500C is the open-top version of the 500 with a folding canvas roof. The hardware below the body is the same. The Abarth performance variant (2012-2019) uses the same hub spec and the same aftermarket window as the standard 500 and 500C. The Abarth's larger brakes and stiffer suspension do not change the bolt pattern, the hub bore, or the practical wheel window. We track the Abarth as its own catalog row for separation but the fitment is interchangeable with the standard 500 of the same year. The Fiat 500 (gasoline) was discontinued in North America after the 2019 model year.

The all-electric Fiat 500e (2024 and up) is the current production Fiat 500 in North America, reintroduced in 2024 as an EV. The 500e shares the 4x98 bolt pattern, the 58.1mm hub bore, and the M12x1.25 lug bolt spec with the older gasoline 500. The electric powertrain does not change the wheel hub geometry. The 500e runs a 16 to 18 inch aftermarket diameter window and accepts 6 to 7.5 inch wide aftermarket wheels. The aftermarket window is narrower than on some larger cars because the 500 is a compact car with limited fender opening. Square (non-staggered) is the factory and recommended configuration on every Fiat 500.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Fiat 500 Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including the Fiat 500. For the 500 that means clearance from the wheel to the fender on the standard 500, the 500C convertible, and the Abarth, gap between the back of the wheel and the suspension across the gasoline and 500e chassis, brake caliper height across base and Abarth packages, hub bore confirmation at 58.1mm, and lug bolt seat depth for M12x1.25 bolts. The 4x98 pattern is similar enough to 4x100 to confuse, so the physical hub measurement is critical rather than relying on a parts-store cross reference. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

Fiat 500 Wheels and Rims FAQ

Get Fiat 500 Wheels Right the First Time

Pick your variant above to see wheels and rims that fit. We measure on every Fiat 500 platform we cover (gasoline 500 / 500C, Abarth, and 500e), track each as its own catalog row, and continue to support the older gasoline cars even as the 500e is the current production model. Find your fit and start enjoying your build sooner.
