Mazda 3 Wheels and Rims

Mazda 3 Aftermarket Wheel Fitment

The Mazda 3 is Mazda's compact sedan and hatchback, in production from the 2004 model year and still being built today. Element Wheels measures the Mazda 3 across four nameplate generations plus the high performance Mazdaspeed3 variant. The 1st gen BK (2004-2009), the 2nd gen BL (2010-2013), the 3rd gen BM and BN (2014-2018), and the current 4th gen BP (2019 and up). The 2010-2013 Mazdaspeed3 is the turbocharged hot hatch trim from inside the BL generation and we track it as its own row in the catalog because its brake and suspension package are different from the regular BL 3. Every Mazda 3 generation runs the same 5x114.3 bolt pattern with a 67.1mm hub bore, the same 5 lug count, and the same M12x1.5 thread pitch. The bolt pattern does not change across generations on this car. What changes is the aftermarket diameter window, the width window, and the fender clearance, which is why we keep generation-specific catalog rows for each. Find your generation below and the fitment specs follow.

Find Your Mazda 3 Generation

Pick your year range to see wheels and rims that fit your specific Mazda 3. The bolt pattern is 5x114.3 with a 67.1mm hub bore on every generation, so the year split here is about diameter range, width window, and fender clearance, not bolt pattern. If you have a 2010-2013 turbo Mazdaspeed3, use the Mazdaspeed3 card below for the brake-cleared fitment box.

The Mazda 3 Bolt Pattern

Every Mazda 3 generation runs 5x114.3 with a 67.1mm hub bore. The imperial nickname for this pattern is 5x4.5 because 114.3mm equals 4.5 inches exactly. The lug count is 5 and the thread pitch is M12x1.5. The bolt pattern is the same on the 1st gen BK (2004-2009), the 2nd gen BL (2010-2013), the 2010-2013 Mazdaspeed3, the 3rd gen BM and BN (2014-2018), and the current 4th gen BP (2019 and up). The hub bore is 67.1mm on every generation as well, so the hub centering does not change either.

One detail to flag because it catches buyers cross-shopping wheels. 5x114.3 is NOT the same as the 5x115 pattern used on some American sedans like the Chrysler 300 and the Dodge Charger. The two patterns sit roughly 0.7mm apart on the hub circle and a wheel built for one will not properly seat on the other. The 5x4.5 imperial nickname refers to 5x114.3 only. When you are shopping, confirm the wheel listing says 5x114.3 specifically. The imperial form of that same pattern is 5x4.5. Compare across the rest of the Mazda lineup at our Mazda wheels and rims hub.

Why the Mazda 3 Generation Changes the Fitment Window

Every Mazda 3 generation shares the same bolt pattern and hub bore, but the diameter range and width window shift as the car evolved. The 1st gen BK (2004-2009) and the 2nd gen BL (2010-2013) accept aftermarket diameters from 15 to 20 inch, in widths from 6 to 8 inch square. The 3rd gen BM and BN (2014-2018) tightens the lower end to 16 inch and lifts the width window slightly to 7 to 8 inch. The current 4th gen BP (2019 and up) opens the window back to 16 to 20 inch on the standard fitment row, and we keep a separate aggressive-fitment row for BP customers running a wider 8.5 to 9 inch wheel with a lower offset. Most aftermarket Mazda 3 buyers on the BP land at 18 or 19 inch with a flush stance.

The Mazdaspeed3 is the high performance trim from inside the 2010-2013 BL generation, with the 2.3 liter turbo and an upgraded factory brake package. We measure the Mazdaspeed3 as its own catalog row because the factory front brake on the Mazdaspeed3 is larger than the brake on a non-turbo BL 3, which tightens the brake clearance window. The bolt pattern, hub bore, lug count, and thread pitch are still the same 5x114.3 / 67.1mm / 5 / M12x1.5 spec, so a wheel that bolts to a regular BL 3 will bolt to a Mazdaspeed3 in lug math. The brake clearance is what we verify separately. The Mazdaspeed3 fitment window measures to 18 to 19 inch in diameter with the larger factory brake cleared.

The Mazda 3 is a square (non-staggered) fitment from the factory on every generation, including the Mazdaspeed3. Same wheel spec front and rear on every trim. Almost every aftermarket Mazda 3 build also runs square because the front wheel drive layout rewards equal grip front to rear and keeps tire rotation simple.

How We Confirm Fitment on Mazda 3 Wheels

Element Wheels measures fitment on the Mazda 3 directly across every generation, including the Mazdaspeed3. For the Mazda 3 that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height (verified separately on the Mazdaspeed3 turbo brake), hub bore confirmation at 67.1mm, lug stud height, and turning clearance with the wheel and tire installed. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

That measurement work is what produced the generation-specific diameter and width windows on this page, and what authorizes the separate Mazdaspeed3 row inside the BL generation. Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

Mazda 3 Wheels and Rims FAQ

Get Mazda 3 Wheels Right the First Time

Pick your generation above to see wheels and rims that fit. We measure the Mazda 3 across every generation from the 1st gen BK through the current 4th gen BP, plus the 2010-2013 Mazdaspeed3 turbo trim as its own catalog row. Find your fit and start enjoying your build sooner.
