Mazda 6 Wheels and Rims

Mazda 6 Aftermarket Wheel Fitment

The Mazda 6 is Mazda's mid-size sedan, sold in North America from the 2003 model year through 2021. Mazda discontinued the 6 in North America after the 2021 model year, so the lineup is now a closed historical range. Element Wheels measures the Mazda 6 across three nameplate generations: the 1st gen GG (2003-2008), the 2nd gen GH (2009-2013), and the 3rd gen GJ (2014-2021). Every Mazda 6 generation runs the same 5x114.3 bolt pattern with a 67.1mm hub bore, the same 5 lug count, and the same M12x1.5 thread pitch. The bolt pattern does not change across generations on this car. What changes is the aftermarket diameter window, the width window, and the fender clearance, which is why we keep generation-specific catalog rows for each. Find your generation below for the fitment specs. Compare across the rest of the Mazda lineup at our Mazda wheels and rims hub.

Find Your Mazda 6 Generation

Pick your year range to see wheels and rims that fit your specific Mazda 6. The bolt pattern is 5x114.3 with a 67.1mm hub bore on every generation, so the split here is about diameter range, width window, and fender clearance, not bolt pattern. The Mazda 6 is a closed range in North America since 2021, so the three generations below cover the entire run.

The Mazda 6 Bolt Pattern

Every Mazda 6 generation runs 5x114.3 with a 67.1mm hub bore. The imperial nickname for this pattern is 5x4.5 because 114.3mm equals 4.5 inches exactly. The lug count is 5 and the thread pitch is M12x1.5. The bolt pattern is the same on the 1st gen GG (2003-2008), the 2nd gen GH (2009-2013), and the 3rd gen GJ (2014-2021). The hub bore is 67.1mm on every generation as well, so the hub centering does not change either. Wheel cross-shopping across Mazda 6 generations is straightforward at the bolt pattern level.

The 5x114.3 / 67.1mm spec on the Mazda 6 is shared across most of the modern Mazda lineup: the Mazda 3, the Mazda CX-9 mid-size SUV, the Mazda MX-5 Miata NC (3rd gen, 2006-2015), and the older Mazda RX-8. The wheels bolt to the same hub across these cars. Body proportion and brake clearance do not always cross between models (the Mazda 6 fender opening is different from a Miata fender opening), but the bolt pattern is consistent.

One detail that catches buyers: 5x114.3 is NOT the same as the 5x115 pattern used on some American sedans (Chrysler 300, Dodge Charger LX, Dodge Challenger). The two patterns sit roughly 0.7mm apart and are not interchangeable. The imperial nickname 5x4.5 refers ONLY to 5x114.3 because 114.3mm equals exactly 4.5 inches. Stick to 5x114.3 / 5x4.5 specifically on a Mazda 6.

Why Each Mazda 6 Generation Has Its Own Fitment Row

The 1st gen GG Mazda 6 (2003-2008) was Mazda's first sport-tuned mid-size sedan and the diameter window starts at 16 inch because the factory offered the original car on smaller wheels. The 2nd gen GH (2009-2013) is similar in fitment to the GG with a slightly wider width window (up to 8.5 inch in our measured range) because the body opened up the fender slightly. The 3rd gen GJ (2014-2021) is where the Mazda 6 became a more athletic mid-size sedan: the diameter window starts at 17 inch, the width window opens to 9 inch, and the brake clearance changed enough that we measure it as its own row even though the bolt pattern stayed the same.

The 2006-2008 Mazdaspeed6 is the turbocharged AWD performance variant of the 1st gen Mazda 6. The Mazdaspeed6 was sold from 2006 through 2008 only and carried an upgraded brake package over the regular GG Mazda 6. Our standard 1st gen GG catalog row is measured on the regular brake package, not the Mazdaspeed6 brake. Bolt pattern and hub bore did not change on the Mazdaspeed6 (still 5x114.3 / 67.1mm / M12x1.5), but the inner-barrel clearance the wheel needs for the front brake is larger. If you have a Mazdaspeed6, contact our team for a free fitment consultation before ordering. This is the kind of detail generic spec calculators do not catch.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Mazda 6 Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including every Mazda 6 generation back to the 2003 GG. For these cars that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height (especially on the Mazdaspeed6 where the brake package is upgraded), hub bore confirmation to the 67.1mm Mazda hub, lug seat geometry for M12x1.5 nuts, and turning clearance at full lock. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

Mazda 6 Wheels and Rims FAQ

Get Mazda 6 Wheels Right the First Time

Pick your generation above to see wheels and rims that fit. We measure on the Mazda 6 across all three nameplate generations (GG, GH, GJ), confirm the 5x114.3 / 67.1mm hub spec separate from the easy-to-confuse 5x115 pattern on American sedans, and route Mazdaspeed6 fitments via a free consultation because the brake clearance is different. Find your fit and start enjoying your build sooner.
