Mazda MX-3 Wheels and Rims

Mazda MX-3 Aftermarket Wheel Fitment

The Mazda MX-3 is the compact sport coupe Mazda built across a single generation, sold in North America from 1992 through 1995 model years on the Mazda EC and EH platform. The car is best known for the GS trim's 1.8 liter K8-ZE V6, a 24 valve narrow angle V6 that is one of the smallest mass production V6 engines ever sold in North America and the reason enthusiasts still chase clean MX-3 GS examples on the used market. Element Wheels measures fitment on the MX-3 directly. The MX-3 runs 4x100 with a 54.1mm hub bore and 12x1.5 lug nuts, the same hub family Mazda used on the contemporary Miata NA and the 1990-1998 Protege BG and BH. The car is front wheel drive end to end and runs square (same width front and rear) on every trim. Pick your generation below.

Find Your Mazda MX-3 Generation

The Mazda MX-3 is a single generation sport coupe. North American sales ran 1992 through 1995 model years. Element Wheels maintains a measured fitment catalog row for the MX-3 covering the full run. Pick the card below to see wheels and rims that fit.

The Mazda MX-3 Bolt Pattern and Hub Bore

Every Mazda MX-3 runs 4x100 with a 54.1mm hub bore and 12x1.5 lug nuts. The 4x100 pattern is one of the most common 4 lug patterns ever used in compact and subcompact cars from the late 1980s into the 2000s. The lug count is 4 and the thread pitch is M12x1.5 across every MX-3 trim from 1992 through 1995. The Element Wheels catalog row for the MX-3 confirms this spec directly. The 4x100 / 54.1mm hub configuration is the same hub family Mazda used on the contemporary Miata NA (1990-1997) and the 1990-1998 Protege BG and BH, so wheels that fit those cars at the lug math level will also lug-bolt to an MX-3.

Hub bore on the MX-3 is 54.1mm, which is the small Mazda 4 lug hub. Most modern aftermarket wheels are designed with a larger centerbore and step down with hub centric rings. A wheel with a centerbore larger than 54.1mm needs hub centric rings to bring the bore down to the MX-3's hub diameter. If your fitment needs rings, they'll be included with the order.

A note on 4x100 fitment across the MX-3 era. 4x100 was used by other compact cars of the period across multiple brands. The bolt pattern is the same number, but the hub bore, the chassis geometry, and the offset window are all different between cars. The MX-3 sits in the Mazda small 4 lug hub family at 54.1mm. Confirm any cross-shopped wheel against the MX-3's hub bore before mounting. Compare across the rest of the Mazda lineup at our Mazda wheels and rims hub.

The MX-3 V6 Trim and Why Enthusiasts Care

The MX-3 lineup ran two engines in North America. The base trim used a 1.6 liter four cylinder. The GS trim used the 1.8 liter K8-ZE V6, a 24 valve narrow angle V6 that produced 130 horsepower with a high revving character. The K8-ZE is one of the smallest mass production V6 engines ever sold in North America, and the GS trim is the version enthusiasts shop for in the used market. The chassis geometry, the bolt pattern (4x100), and the hub bore (54.1mm) are the same across the base trim and the GS V6 trim, so wheel fitment is consistent across the lineup. Factory wheels stepped through 14 inch on the base trim and 15 inch on the GS trim. Most aftermarket MX-3 builds step up to 16 or 17 inch.

The MX-3 runs square (same width front and rear) on every trim. The car is front wheel drive and there is no factory staggered MX-3 in any year. Most aftermarket MX-3 builds run square as well because the chassis is engineered around equal grip front to rear and tire rotation is part of normal maintenance. Brake size is matched front to rear from the factory on every trim in our catalog row.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Mazda MX-3 Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including the 1992-1995 MX-3. For the MX-3 that means clearance from the wheel to the front fender on a compact sport coupe body, gap between the back of the wheel and the front strut and brake caliper, hub bore confirmation at 54.1mm on the small Mazda 4 lug hub, lug seat geometry on the M12x1.5 thread, and turning clearance with the wheel and tire installed at full lock on a front wheel drive chassis. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

If you are running a GS V6 MX-3 with coilovers, a big brake kit, or any chassis modification, send us the year and the modifications and we can confirm the right wheel before you order. Every recommendation is backed by the Fitment Guarantee.

Mazda MX-3 Wheels and Rims FAQ

Get Mazda MX-3 Wheels Right the First Time

Pick the generation card above to see wheels and rims that fit. We measure the 1992-1995 MX-3 directly and we run a fitment consultation for any GS V6 build or modified chassis. Find your fit and start enjoying your build sooner.
