Lexus HS Wheels and Rims

Lexus HS Aftermarket Wheel Fitment

The Lexus HS 250h is Lexus's first dedicated hybrid sedan and the only HS generation Lexus brought to the US market. It ran from 2010 through 2012 as a limited production hybrid four-door, then Lexus discontinued the model after a short three-year run. Underneath, the HS 250h is built on the Toyota MC platform shared with the Toyota Avensis. Element Wheels measures fitment for the HS 250h directly. The bolt pattern is 5x114.3 with a 60.1mm hub bore. That is the mainstream Lexus pattern carried by the IS, ES, GS, RC, and RX, so the HS reads as a typical Lexus on lug math, not as a Prius-platform sibling. Front and rear brake are matched in size on every HS 250h in our catalog. Pick the trim below for the fitment specs that apply to your specific HS.

Find Your Lexus HS

Pick your HS to see wheels and rims that fit. The HS 250h ran a single trim and a single drivetrain across its 2010-2012 US production span. The bolt pattern is 5x114.3 with a 60.1mm hub bore on every HS, and the brake hardware is matched front and rear.

The Lexus HS Bolt Pattern

Every Lexus HS 250h uses 5x114.3 with a 60.1mm hub bore. That is the mainstream Lexus pattern shared with the IS, ES, GS, RC, and RX. The 5x114.3 pattern is also written as 5x4.5 in imperial. That imperial nickname refers ONLY to 5x114.3 (114.3mm = 4.5 inches) and not to 5x115. A wheel listed for 5x115 (current Chrysler 300, Dodge Charger LX, some Mustang trims) will NOT bolt onto a Lexus HS, even though the difference reads as less than a millimeter on a tape measure. The hub bore stays 60.1mm across every HS variant.

One platform note worth knowing. Lexus brought two hybrid models into the US lineup at around the same time. The HS 250h is the hybrid sedan (2010-2012) and runs the mainstream Lexus bolt pattern of 5x114.3 / 60.1mm. The CT 200h is the hybrid hatch (2011-2017) and runs 5x100 / 54.1mm because it sits on a different Toyota platform underneath. The two hybrid Lexus cars from the same era do NOT share wheels, even though both wear the Lexus badge and both run Hybrid Synergy Drive. Compare across the rest of the Lexus lineup at our Lexus wheels and rims hub.

The HS 250h: Lexus's First Dedicated Hybrid Sedan

The HS 250h is the only Lexus HS generation that ever reached US showrooms. It was Lexus's first purpose-built hybrid model in the brand's lineup, distinct from earlier Lexus hybrids like the GS 450h and RX 400h, which were hybrid versions of existing gas-powered platforms. The HS was designed from the start as a hybrid. Underneath, it sits on the Toyota MC platform shared with the Toyota Avensis. The powertrain is the 2AZ-FXE 2.4L Atkinson-cycle inline-four paired with the Toyota Hybrid Synergy Drive system. Lexus brought the HS to the US for the 2010 model year and discontinued it after the 2012 model year. The total US production run is short, which makes the HS 250h a relatively low-volume car on the used market.

For wheel fitment, the HS 250h runs the mainstream Lexus bolt pattern (5x114.3 / 60.1mm) rather than the Toyota Prius pattern. That is what separates it from the CT 200h, which sits on the Prius E150 platform and inherits the Prius bolt pattern. The HS is closer to an IS or ES sedan on lug math, even though the powertrain is hybrid. Front and rear brake are matched in size on every HS 250h in our catalog, the factory builds shipped square, and our measured aftermarket window keeps front and rear width matched.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Lexus HS Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including the HS 250h across its 2010-2012 production run. For the HS that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height, hub bore confirmation, lug seat geometry, and turning clearance with the wheel and tire installed. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do. That measurement work is what produced the 17 inch diameter floor and the 7 inch width floor on this page, which sit slightly lower than what a larger Lexus sedan typically carries.

Lexus HS Wheels and Rims FAQ

Get Lexus HS Wheels Right the First Time

Pick your trim above to see wheels and rims that fit. We measure on the HS 250h directly, confirm the 5x114.3 / 60.1mm pattern on every listing, and keep the aftermarket window honest about ride quality and unsprung weight. Find your fit and start enjoying your build sooner.
