Mazda Mazdaspeed Wheels and Rims

Mazda Mazdaspeed Aftermarket Wheel Fitment

Mazdaspeed was Mazda's in-house performance division and the badge that produced three distinct US-market hot hatches and sedans during the 2003-2013 window: the 2003 Mazdaspeed Protege, the 2006-2007 Mazdaspeed6, and the 2007-2013 Mazdaspeed3 (across two generations, the 1st gen BK in 2007-2009 and the 2nd gen BL in 2010-2013). Three different cars, one performance lineage. The common thread for wheel fitment is the 5x114.3 bolt pattern with a 67.1mm hub bore and 12x1.5 lug nuts. That spec is shared across the Mazdaspeed lineup. What changes between models is the diameter range, the width window, the drivetrain (the Mazdaspeed6 is the only AWD Mazdaspeed), and the brake clearance behind the wheel face. Element Wheels catalogs measured fitment for the Mazdaspeed Protege and the 2010-2013 Mazdaspeed3 directly. For the Mazdaspeed6 and the 1st gen Mazdaspeed3, our team runs a fitment consultation to confirm the right wheel on those specific cars. Pick your model card below.

Find Your Mazda Mazdaspeed

Pick your model and year to see wheels and rims that fit your specific Mazdaspeed. The 5x114.3 / 67.1mm / 12x1.5 spec is common across the lineup. What changes is diameter range, width window, drivetrain, and brake clearance. The Mazdaspeed Protege and the 2010-2013 Mazdaspeed3 are in the active catalog. For the Mazdaspeed6 and the 2007-2009 Mazdaspeed3, contact our team for a free fitment consultation.

The Mazdaspeed Bolt Pattern and Hub Bore

Every Mazdaspeed in the 2003-2013 production window runs 5x114.3 with a 67.1mm hub bore and 12x1.5 lug nuts. The 5x114.3 pattern is also expressed as 5x4.5 in imperial nickname (114.3mm equals 4.5 inches). Be careful with the common mix-up. 5x114.3 is NOT the same as 5x115. Those two patterns are 0.7mm apart at the bolt circle and they do not cross. The imperial 5x4.5 nickname refers only to 5x114.3.

Hub bore is 67.1mm across the Mazdaspeed lineup. A wheel with a centerbore larger than 67.1mm needs hub centric rings to bring the bore down to the hub diameter. The 5x114.3 / 67.1mm spec on the Mazdaspeed lineup matches the rest of the Mazda 3 and Mazda 6 lineage from the mid-2000s forward, which is why aftermarket support for Mazdaspeed wheels has always been strong, the platform shares the most common Mazda hub interface in the catalog. Compare across the rest of the Mazda lineup at our Mazda wheels and rims hub.

The Three Mazdaspeed Cars and What Is Different About Each

Mazdaspeed produced three US-market performance cars during the 2003-2013 window. Each shares the 5x114.3 / 67.1mm bolt-pattern spec with the broader Mazda lineup, but each has its own chassis, drivetrain, and brake package that affects the wheel fitment box.

• Mazdaspeed Protege (2003): The first US Mazdaspeed. A turbocharged 2.0L 4-cylinder front wheel drive Protege sedan. Mazda built the car as a low-volume one-year-only model with Racing Beat tuning. 5x114.3 / 67.1mm / 12x1.5 lug nuts. Element measured aftermarket window: 17-18 inch diameter, 7-7.5 inch width square. In the Element catalog.
• Mazdaspeed6 (2006-2007): Mazdaspeed's only AWD car. A turbocharged 2.3L MZR DISI 4-cylinder all wheel drive Mazda 6 sedan with a 6-speed manual. Shares the 5x114.3 / 67.1mm bolt pattern with the rest of the Mazda 6 lineup of that era. Not currently in the Element measured catalog. Contact our team for a fitment consultation.
• Mazdaspeed3 1st gen BK (2007-2009): Front wheel drive turbocharged Mazda 3 hatchback. Same 2.3L MZR DISI turbo as the Mazdaspeed6 but transverse-mounted with FWD. Shares the 5x114.3 / 67.1mm bolt pattern with the rest of the Mazda 3 BK lineup. Not currently in the Element measured catalog. Contact our team for a fitment consultation.
• Mazdaspeed3 2nd gen BL (2010-2013): The facelifted Mazdaspeed3 on the BL Mazda 3 chassis. Same 2.3L MZR DISI turbo, FWD, 6-speed manual, with subtle styling and chassis revisions over the 1st gen. 5x114.3 / 67.1mm / 12x1.5 lug nuts. Element measured aftermarket window: 18-19 inch diameter, 7-8 inch width square. In the Element catalog.

Square fitment is the default on every Mazdaspeed. None of these cars came with a factory staggered setup and Element does not recommend staggered builds on the platform. The chassis are FWD (Protege, both Mazdaspeed3 generations) or AWD (Mazdaspeed6). Both drivetrain types favor matched-width wheels for tire rotation and chassis balance.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Mazdaspeed Wheels

Element Wheels measures fitment on the Mazdaspeed Protege and the 2010-2013 Mazdaspeed3 directly. For these cars that means clearance from the wheel to the fender on both axles (the Mazdaspeed3 BL has tighter front fender wells than a base Mazda 3 because of the wider front track and the suspension package), gap between the back of the wheel and the suspension links, brake caliper height across the factory package, hub bore confirmation at 67.1mm, and lug nut seat geometry for the 12x1.5 nuts. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

Mazda Mazdaspeed Wheels and Rims FAQ

Get Mazdaspeed Wheels Right the First Time

Pick your model card above to see wheels and rims that fit. We measure the Mazdaspeed Protege and the 2010-2013 Mazdaspeed3 directly, and we run a fitment consultation for the Mazdaspeed6 and the 2007-2009 Mazdaspeed3. The 5x114.3 / 67.1mm / 12x1.5 spec is common across the lineup. Find your fit and start enjoying your build sooner.
