Mazda RX-7 Wheels and Rims

Mazda RX-7 Aftermarket Wheel Fitment

The Mazda RX-7 is the rotary-powered sports coupe that ran across three distinct generations: the first generation SA22C and FB (1979-1985), the second generation FC (1986-1991), and the third generation FD (1993-1995 in the US, 1992-2002 globally). The FD is the icon. Sequential twin-turbocharged 13B-REW rotary, double wishbone suspension front and rear, sub-2,800-pound curb weight, and one of the most aggressively-shaped coupe bodies of its era. Element Wheels currently catalogs measured aftermarket fitment for the 1993-1995 FD RX-7. The 5x114.3 bolt pattern with 67.1mm hub bore and 12x1.5 lug nuts is what every RX-7 wheel buyer needs to know first. The FD ships from the factory with square 16x8 wheels but factory width allowance and our measured aftermarket window both support staggered setups, which is where most modern FD builds end up. Pick the generation card below for the fitment specs that apply to your RX-7.

Find Your Mazda RX-7 Generation

Pick your generation to see wheels and rims that fit your specific RX-7. Element Wheels currently maintains a measured fitment catalog for the 1993-1995 FD RX-7. If you have an earlier SA22C, FB, or FC RX-7, contact our team for a fitment consultation. We can verify the right wheel for an older RX-7 based on the specific year and trim.

The Mazda RX-7 Bolt Pattern and Hub Bore

The 1993-1995 FD RX-7 runs 5x114.3 with a 67.1mm hub bore and 12x1.5 lug nuts. The 5x114.3 pattern, also expressed as 5x4.5 in imperial nickname (114.3mm equals 4.5 inches), is the same pattern Mazda used across most of the rear drive lineup of that era and is one of the most common 5-lug patterns in the world. Be careful of the common cross-up: 5x114.3 is NOT the same pattern as 5x115. Those are 0.7mm apart at the bolt circle, which is enough to stress the lug studs over time. The imperial 5x4.5 nickname refers ONLY to 5x114.3.

Hub bore on the FD is 67.1mm. A wheel with a centerbore larger than 67.1mm needs hub centric rings to bring the bore down to the FD's hub diameter. Compare across the rest of the Mazda lineup at our Mazda wheels and rims hub.

For older RX-7 generations: the first generation SA22C and FB (1979-1985) and the second generation FC (1986-1991) are different chassis with different lug specs from the FD. We do not extrapolate older generation fitment from the FD catalog row. If you have an SA22C, FB, or FC RX-7, reach out for a free fitment consultation and we can confirm the right bolt pattern and aftermarket window for your specific year.

Why The FD RX-7 Is The Wheel Buyer's RX-7

The FD RX-7 ships from the factory with a square 16x8 fitment, the same wheel front and rear. That was the lightweight balance Mazda was after when the car came out in 1992. The aftermarket community took the FD in a different direction. Because the rear fender well is large and the chassis tolerates a wider rear wheel without rubbing, staggered setups became the default aftermarket build, especially as engine builders extracted more power from the 13B-REW. Element Wheels supports both. The fitment catalog row for the FD has separate width windows for front and rear, with a deliberately wider rear allowance because that is what the rear of the FD can take.

The brake package on the factory FD is matched front to rear. The FD does not have a Brembo or factory big-brake option that splits fitment by trim. Customers running an aftermarket big brake kit on the front should verify the specific kit's caliper height before ordering wheels.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Mazda RX-7 Wheels

Element Wheels measures fitment on the FD RX-7 directly. For this car that means clearance from the wheel to the fender on both axles (the FD has tight fender wells front and rear by design), gap between the back of the wheel and the suspension links, brake caliper height, hub bore confirmation at 67.1mm, lug nut seat geometry for the 12x1.5 nuts, and the wider rear allowance the FD chassis can take without rubbing. The FD is one of those cars where the spec sheet says one thing and the chassis says another. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

Mazda RX-7 Wheels and Rims FAQ

Get Mazda RX-7 Wheels Right the First Time

Pick the generation card above to see wheels and rims that fit. We measure the 1993-1995 FD RX-7 directly, support both square and staggered builds, and run a fitment consultation for owners of earlier SA22C, FB, or FC RX-7 cars or for anyone running an aftermarket big brake kit. Find your fit and start enjoying your build sooner.
