Suzuki SX4 Wheels and Rims

Suzuki SX4 Aftermarket Wheel Fitment

The Suzuki SX4 is the compact hatchback and sedan Suzuki sold in the US between 2007 and 2013. The car was developed jointly by Suzuki and Fiat on a shared platform (the European version is the Fiat Sedici, built at the same Magyar Suzuki facility in Hungary as the Suzuki version). The SX4 ran one bolt pattern across the entire US production: 5x114.3 with a 60.1mm hub bore, 12x1.25 lug studs, and five lug per corner. Body styles were the 5-door hatchback (sold as the SX4 Crossover with optional Suzuki iAWD all-wheel-drive) and the 4-door sedan from 2008 forward, both on the same fitment box. The drivetrain choice (front-wheel-drive or iAWD all-wheel-drive) does NOT change the bolt pattern, hub bore, diameter range, or width range, so the same wheel that fits a front-drive SX4 fits the iAWD SX4 of the same year. Element Wheels measures the SX4 directly to keep the aftermarket fitment box honest.

Find Your Suzuki SX4

The Suzuki SX4 ran one generation in the US (2007-2013). Pick your year below to see wheels and rims that fit.

The Suzuki SX4 Bolt Pattern

The Suzuki SX4 runs 5x114.3 with a 60.1mm hub bore. 5x114.3 is also written as 5x4.5 in imperial (114.3mm = 4.5 inches). The 5x4.5 nickname applies to 5x114.3 ONLY and not to 5x115. A wheel listed as 5x115 (Chrysler 300, Dodge Charger LX) will NOT bolt onto an SX4 even though the millimeter difference looks small. Confirm 5x114.3 specifically before buying. Lug count is five per corner and thread pitch is M12x1.25 with a tapered lug seat. The 60.1mm hub bore is the small-car centering bore common to compact 5x114.3 platforms.

Inside the Suzuki lineup, the SX4 shares 5x114.3 / 60.1mm with the 2006-2013 Suzuki Grand Vitara (unibody) and the 2010-2013 Suzuki Kizashi mid-size sedan. The compact-Suzuki 5x114.3 / 60.1mm fitment carries across the small-car family of that era. Compare across the rest of the Suzuki lineup at our Suzuki wheels and rims hub.

Why Drivetrain Choice Does Not Change SX4 Fitment

The SX4 was sold in the US with two drivetrain choices. Front-wheel-drive on the sedan and base hatchback. Optional Suzuki iAWD all-wheel-drive on the SX4 Crossover hatchback trim. Both share the same wheel hardware. The bolt pattern (5x114.3), hub bore (60.1mm), thread pitch (M12x1.25), brake hardware (matched front and rear), diameter range, and width range all carry across both drivetrains. The iAWD on the SX4 is a viscous-coupling all-wheel-drive system that defaults to front-drive and engages the rear axle when the front loses traction. It does not require a different wheel or tire spec from the front-drive version. The same wheel that fits a 2010 SX4 sedan (front-drive) fits a 2010 SX4 Crossover (iAWD) at the same diameter, width, and offset.

Cross-shop implication. Inside the Suzuki family, a 2006-2013 Grand Vitara (unibody) or a 2010-2013 Suzuki Kizashi wheel will share lug math and hub centering with the SX4 (all run 5x114.3 / 60.1mm). Outside Suzuki, the SX4 shares its underlying platform with the European Fiat Sedici (same factory, same engineering team). A Fiat Sedici wheel of the same era shares lug math, hub centering, and the broader fitment geometry, though the Sedici is not a US-market car. Width and offset still need to be confirmed against the SX4 body specifically.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Suzuki SX4 Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including the SX4. For the SX4 that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height, hub bore confirmation at 60.1mm, and turning clearance with the wheel and tire installed. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We do not pull specs from manufacturer sheets the way most retailers do. That measurement work is what produced the 16-20 inch diameter window and the 7-8 inch width range for the SX4, and why we are confident the same fitment box applies across both the front-drive and the iAWD all-wheel-drive trim.

Suzuki SX4 Wheels and Rims FAQ

Get Suzuki SX4 Wheels Right the First Time

Pick your SX4 above to see wheels and rims that fit. We measure on the SX4 directly, confirm 5x114.3 and 60.1mm on every listing, and keep the aftermarket window honest about ride quality and brake clearance across both drivetrain options. Find your fit and start enjoying your build sooner.
