Dodge Viper Wheels and Rims

Dodge Viper Aftermarket Wheel Fitment

The Dodge Viper is Chrysler's halo V10 supercar, rear wheel drive, built in three production eras across 22 years. Element Wheels measures fitment on the second-generation (1996-2002), third-generation (2003-2010), and fifth-generation (2013-2017) Viper. Every Viper we cover uses the same unique 6x114.3 bolt pattern with a 71.6mm hub bore, M12x1.5 lug thread, and 6 lugs. The Viper is a must-be-staggered car. The front and rear widths are different by design, with wider rear wheels carrying the V10's torque and narrower fronts (still wide by sports car standards) for steering. Larger front brakes than rear is standard performance car geometry on the Viper. Pick the generation below.

Find Your Dodge Viper Generation

Pick your generation to see wheels and rims that fit your specific Viper. The bolt pattern stays 6x114.3 across every Viper era we measure, but diameter, width, and offset windows shift across generations as Chrysler revised the body and the brake package. Viper production paused 2011-2012 between the third and fifth generations; no Viper was built in those years.

The Dodge Viper Bolt Pattern

Every Dodge Viper from the 1996 second generation through the 2017 fifth generation uses a 6x114.3 bolt pattern with a 71.6mm hub bore and an M12x1.5 lug thread. 6 lugs, not 5. This is one of the very few passenger cars on the road that uses a 6-lug pattern. Chrysler chose the 6-lug hub to handle the Viper's V10 torque, the weight transfer of a 2-seat front-engine layout, and the wide rear tire that the platform required from launch.

6x114.3 is also written as 6x4.5 in imperial (114.3mm = 4.5 inch). Same pattern, two naming conventions. Six-lug 114.3 is far more common on midsize trucks than on cars, which is part of what makes the Viper hub unusual. The 71.6mm centerbore is also a Viper-specific spec; it does not cross-reference cleanly with most 6-lug truck applications. Compare across the rest of the Dodge lineup at our Dodge wheels and rims hub.

Generation Differences Across the Dodge Viper

The Viper kept the same 6x114.3 hub geometry across the three generations we measure, but the diameter, width, and offset windows shifted with each redesign. The second generation (1996-2002) ran 17 to 18 inch from the factory and accepts the widest range of older aftermarket styling. The third generation (2003-2010) jumped to 18 to 19 inch factory sizing with a tighter offset window pulled in by the revised body and brake package. The fifth generation (2013-2017) brought the most aggressive factory fitment, with 18 to 19 inch standard and 19 to 20 inch on the ACR trim that came with track-targeted aero, brakes, and tire sizes.

The Viper is a must-be-staggered car on every generation we cover. Square fitment is not an option. The rear wheels are meaningfully wider than the fronts because the V10 drives the rear and the chassis was engineered around a wide rear contact patch. Front brakes are larger than rear on every Viper, which is standard on a performance car of this weight and power. The ACR trim on the third and fifth generations runs a more aggressive brake package than the standard Viper; clearance on the ACR is tighter and the rim style needs to be confirmed against the caliper specifically.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Dodge Viper Wheels

Element Wheels measures fitment on the Viper directly, across the second, third, and fifth generations, and across the ACR trim where it differs from the standard Viper. For the Viper that means hub bore confirmation at 71.6mm, clearance from the wheel to the fender on the wide rear quarters, gap between the back of the wheel and the lower control arm, brake caliper height on the larger front brake assembly (and the ACR's bigger caliper where applicable), lug seat depth, and lug thread confirmation at M12x1.5. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull these from manufacturer spec sheets the way most retailers do.

Dodge Viper Wheels and Rims FAQ

Get Dodge Viper Wheels Right the First Time

Pick your generation above to see wheels and rims that fit. We measure across every Viper era we cover, and the catalog reflects what actually clears the wide rear quarters, the front brake assembly, and the ACR's tighter caliper package. Find your fit and start enjoying your build sooner.
