Kia EV6 Wheels and Rims

Kia EV6 Aftermarket Wheel Fitment

The Kia EV6 is Kia's electric crossover, on sale in North America from the 2022 model year and up. The EV6 rides on the Hyundai-Kia E-GMP platform, the same dedicated electric platform that underpins the Hyundai Ioniq 5, the Hyundai Ioniq 6, and the Genesis GV60. Every EV6 uses a 5x114.3 bolt pattern with a 67.1mm hub bore, an M12x1.5 thread, and 5 lugs. The fitment box does not change between rear wheel drive and all wheel drive EV6 trims. The performance-oriented EV6 GT carries larger front brakes than the standard EV6, so on the GT specifically the smallest aftermarket diameter that clears safely is a step up from the base trims. Both trims sit on the same 5x114.3 / 67.1mm hub pattern. The EV6 is an EV crossover that weighs more than a comparable internal combustion crossover because of the floor-mounted battery pack, which means tire load rating matters more on this car than the wheel diameter chase. Find your trim below and the fitment specs follow.

Find Your Kia EV6 Trim

Pick your trim to see wheels and rims that fit your specific EV6. The standard EV6 (Light, Wind, GT-Line) and the performance EV6 GT share the 5x114.3 / 67.1mm bolt pattern and the same aftermarket diameter window in our catalog. The GT carries larger front brake hardware than the standard EV6, so the smallest aftermarket diameter that clears the GT caliper is a step up. Both rear wheel drive and all wheel drive EV6 trims share the same wheel fitment box.

The Kia EV6 Bolt Pattern

Every Kia EV6 (2022 and up) runs a 5x114.3 bolt pattern with a 67.1mm hub bore. The imperial nickname for this pattern is 5x4.5, because 114.3mm equals 4.5 inches exactly. The lug count is 5 and the thread pitch is M12x1.5. The pattern does not change between the Light, Wind, GT-Line, and GT trims, and it does not change between the rear wheel drive and all wheel drive EV6. Hyundai Motor Group uses the same 5x114.3 / 67.1mm pattern across the E-GMP platform, which includes the Hyundai Ioniq 5, Hyundai Ioniq 6, and Genesis GV60. Within the E-GMP family the wheels bolt to the same hub, though factory offset windows and brake clearance still need to be confirmed for each specific car.

One detail worth flagging because we see it confuse buyers. 5x114.3 is NOT the same pattern as 5x115. The two sit roughly 0.7mm apart on the hub circle and a wheel built for one will not properly seat on the other. The 5x4.5 imperial nickname refers to 5x114.3 only. The 5x115 pattern used on some American sedans (Chrysler 300, Dodge Charger and Challenger, Cadillac CTS, and others) is a different bolt pattern and those wheels will not fit your EV6. When you are shopping, confirm the wheel listing says 5x114.3 specifically. Compare across the rest of the Kia lineup at our Kia wheels and rims hub.

Why the EV6 Trim and Battery Weight Change the Wheel Pick

The EV6 lineup has the standard trims (Light, Wind, GT-Line) on one front brake spec, and the performance EV6 GT on a larger front brake spec. The GT brake is taller and reaches further out from the hub than the standard caliper. The bolt pattern and hub bore are identical. The diameter and width window is similar in our catalog, but the GT clears the smallest aftermarket diameters less easily than the standard trims because of the front caliper height. Front larger than rear is the normal configuration on a performance crossover, so the GT brake difference is expected, not a quirk.

The EV6 carries a floor-mounted battery pack and weighs more than a comparable internal combustion crossover. That weight changes which tires we recommend more than which wheels we recommend. The tire load rating for a wheel-and-tire package on an EV6 needs to support the EV's curb weight plus passengers, and we publish package load ratings that account for the heavier EV chassis. The wheel diameter and width windows stay inside the published box. Rear wheel drive and all wheel drive EV6 trims share the same fitment box because the front and rear suspension geometry on the E-GMP platform is identical across drivetrains.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Kia EV6 Wheels

Element Wheels measures fitment on the EV6 directly across the standard and GT trims. For the EV6 that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height on both the standard and the GT front brake, hub bore confirmation at 67.1mm, lug stud height, and turning clearance with the wheel and tire installed. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

That measurement work is what produced the trim-specific fitment windows on this page. The EV6 is currently produced (2022 and up), so our catalog grows as we measure newer model year cars and the GT trim. The bolt pattern, hub bore, thread, and lug count are confirmed against the E-GMP platform spec and consistent across the Hyundai Ioniq 5, Hyundai Ioniq 6, and Genesis GV60 siblings.

Kia EV6 Wheels and Rims FAQ

Get Kia EV6 Wheels Right the First Time

Pick your trim above to see wheels and rims that fit. We measure the EV6 across the standard and GT trims on the same E-GMP platform that underpins the Hyundai Ioniq 5, Hyundai Ioniq 6, and Genesis GV60. The 5x114.3 / 67.1mm pattern stays the same across the lineup. The trim-specific brake clearance is what changes. Find your fit and start enjoying your build sooner.
