Kia Niro Wheels and Rims

Kia Niro Aftermarket Wheel Fitment

The Kia Niro is the compact hybrid and EV crossover Kia launched in the United States for the 2017 model year. Element Wheels measures the Niro across both generations: the 1st gen DE (2017-2022) and the current 2nd gen SG2 (2023 and up). Bolt pattern is 5x114.3 with a 67.1mm hub bore and a 12x1.5 lug thread on every Niro in our catalog, and the spec is identical across the Hybrid (HEV), Plug-in Hybrid (PHEV), and Niro EV powertrain variants within each generation. The Niro is a square (non-staggered) fitment with matched front and rear wheel widths and no factory stagger to respect. The 2nd gen Niro is currently produced; the bolt pattern and hub bore have not changed across the generation transition. Pick your generation below for the fitment specs that apply to your specific Niro.

Find Your Kia Niro Generation

Pick your generation to see wheels and rims that fit your specific Niro. The 1st gen DE is the original 2017-2022 hybrid crossover. The 2nd gen SG2 is the redesigned 2023 and up car. Both generations use the same 5x114.3 / 67.1mm bolt pattern, but the overall fitment window is measured separately per generation.

The Kia Niro Bolt Pattern

Every Kia Niro in our catalog uses 5x114.3 with a 67.1mm hub bore and a 12x1.5 lug thread. The imperial nickname for 5x114.3 is 5x4.5, since 114.3mm equals exactly 4.5 inches. That pattern is the modern Hyundai-Kia compact and midsize unibody crossover standard, shared with the Kia Soul, the Kia Sportage, the Hyundai Kona, the Hyundai Tucson, and the Hyundai-Kia mid-size sedan and crossover family in general. It is also one of the most common 5-lug patterns in the modern automotive market more broadly, used on the Honda Civic from 2004 forward, the Nissan Altima, most Toyota Camry generations, and the Mazda3 and Mazda6.

Worth flagging because we see it confuse buyers. 5x114.3 is NOT the same as 5x115. The two patterns sit about 0.7mm apart on the hub circle and a wheel built for one will not properly seat on the other. The 5x4.5 imperial nickname refers to 5x114.3 only. The 5x115 pattern used on the Chrysler 300, Dodge Charger, and Cadillac CTS will not fit a Niro. Stick to 5x114.3 / 5x4.5 specifically.

The Niro bolt pattern has not changed across the 2023 redesign. The 1st gen DE (2017-2022) and the 2nd gen SG2 (2023 and up) both run 5x114.3 / 67.1mm with the 12x1.5 thread pitch. Compare across the rest of the Kia lineup at our Kia wheels and rims hub.

Niro Hybrid, Plug-in Hybrid, and EV Fitment

The Niro is sold in three powertrain configurations in the United States: the Niro Hybrid (HEV), the Niro Plug-in Hybrid (PHEV), and the Niro EV (a battery-electric crossover). All three powertrains within a generation share the same bolt pattern, hub bore, and thread pitch. Bolt pattern is 5x114.3, hub bore is 67.1mm, thread is 12x1.5 across the board. The Niro EV carries more curb weight than the HEV and PHEV variants because of its battery pack, so load rating on the tire is the spec to confirm when sizing for an EV. Wheel selection itself is the same: a wheel that fits a Niro HEV will fit a Niro EV of the same generation, with the tire load rating being the EV-specific check.

The Niro is a square (non-staggered) fitment across both generations and every powertrain. The same wheel spec works front and rear and there is no factory stagger to respect.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Kia Niro Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including both Niro generations. For the Niro that means clearance from the wheel to the fender, gap between the back of the wheel and the front suspension, brake caliper height, hub bore confirmation on the 67.1mm hub, lug seat geometry across the 12x1.5 thread pitch, turning clearance at full lock, and tire load rating cross-check on the heavier Niro EV. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do.

Kia Niro Wheels and Rims FAQ

Get Kia Niro Wheels Right the First Time

Pick your generation above to see wheels and rims that fit. We measure on both Niro generations, carry the same 5x114.3 / 67.1mm spec across Hybrid, Plug-in Hybrid, and EV powertrains, and flag tire load rating as the EV-specific check. Find your fit and start enjoying your build sooner.
