McLaren 650S Wheels and Rims

McLaren 650S Aftermarket Wheel Fitment

The 2014-2016 McLaren 650S is McLaren's Super Series mid-engine supercar, the direct evolution of the 12C and the immediate predecessor to the 720S. It was built around the carbon fiber MonoCell tub and powered by an M838T twin-turbocharged 3.8-liter V8 producing 641 horsepower in standard tune. The 650S family includes the 650S Coupe, the 650S Spider, and the limited-run 650S Can-Am Edition. Every 650S uses a 5x112 bolt pattern with a 57.1mm hub bore and M14x1.5 lug bolts. The 650S is a must-staggered car from the factory with a wider rear wheel and tire than the front. The front brake package is larger than the rear, with carbon ceramic Brembos that came standard. Element Wheels measures 650S fitment directly on the car at our fitment facility in Chandler, Arizona, including the lighter forged options shipped on the 650S Spider and Can-Am. Pick your variant below for wheels and rims fit-tested on the 650S.

Find Your McLaren 650S Variant

Every 650S Coupe, 650S Spider, and 650S Can-Am shares the same bolt pattern, hub bore, and staggered front-vs-rear geometry. All three variants ride on the same MonoCell carbon tub with the same wheel mounting interface, the same brake hardware family, and the same suspension geometry, so a wheel that fits one 650S will fit any 650S on the same fitment math.

The McLaren 650S Bolt Pattern and Lug Bolts

Every 2014-2016 McLaren 650S uses a 5x112 bolt pattern with a 57.1mm hub bore. The spec is identical across the 650S Coupe, the 650S Spider, and the 650S Can-Am, and it matches the rest of the McLaren lineup including the 12C, the 570S, the 570GT, the 600LT, the 675LT, the 720S, the 765LT, and the 750S. The 5x112 pattern is the same VW Group passenger-car spec used on most modern Audi sedans, the first-generation Audi R8, the Lamborghini Gallardo, and the 5-lug Lamborghini Huracan. McLaren uses the same lug count and the same thread spec, but the chassis, suspension, and brake hardware are McLaren-specific. A wheel built for a 5x112 Audi or Lamborghini will not necessarily clear the 650S front brake caliper, which is why we measure on the McLaren platform directly.

The 650S mounts wheels with lug bolts rather than lug nuts on studs. A lug bolt is a single fastener that threads directly into the hub, so the wheel is held to the hub by the bolt itself rather than dropped onto pre-installed studs. The thread spec on the 650S is M14x1.5. There is no stud to align the wheel before tightening, so the hub-centric fit on the 57.1mm bore and the correct bolt length both matter more on a 650S than on a stud-and-nut car. The wrong bolt length is the most common 650S installation mistake we see, so we ship the correct bolts with every McLaren 650S wheel order. Compare across the rest of the McLaren lineup at our McLaren wheels and rims hub.

Why Every McLaren 650S Runs Staggered Fitment

The 650S is a mid-engine, rear-drive McLaren with a 3.8-liter twin-turbocharged V8 mounted behind the cabin. The rear tires put down the power and the rear track is wider than the front, so McLaren specs a wider rear wheel and tire on every 650S. From the factory the 650S ran a 19x8.5 front and a 20x11 rear, paired with 235/35R19 fronts and 305/30R20 rears. The 650S Can-Am followed the same staggered approach with lighter forged wheels and a track-focused tire package. Element's aftermarket window on the 650S covers 19 to 20 inch diameter, with a 9 inch front width and 11 to 12 inch rear widths. We do not recommend square setups on a 650S. The chassis is engineered around the staggered geometry and the rear arches are physically wider than the fronts.

The 650S has a larger front brake package than rear. That is normal on a performance car of this class, and on the 650S the difference is especially pronounced because every 650S shipped with carbon ceramic Brembos as standard equipment. The front carbon ceramic rotor sits at 394mm with a 6-piston caliper, while the rear runs a 380mm rotor with a 4-piston caliper. The front wheel needs more inner-barrel clearance for the larger front caliper, which is one of the variables we measure on the 650S directly rather than estimating from factory spec sheets. This is also why a wheel built for the rear of a 650S will often not clear the front caliper even when the bolt pattern and offset numbers look workable on paper.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on McLaren 650S Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including the McLaren 650S. For the 650S that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height measured separately on the front and rear because the front carbon ceramic package is larger, hub protrusion past the mounting surface, and the lug bolt seat depth that is specific to European exotics. The 650S Coupe, the 650S Spider, and the 650S Can-Am all share the same MonoCell carbon tub, so a fitment that works on one variant works across the rest of the 650S family. The 650S also predates the 720S MonoCage II tub, so we confirm the fitment box on the 650S itself rather than carrying numbers across from the newer Super Series cars. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the car. We don't pull specs from manufacturer sheets the way most retailers do.

McLaren 650S Wheels and Rims FAQ

Get McLaren 650S Wheels Right the First Time

Pick your variant above to see wheels and rims that fit. We measure on the 650S platform, account for the carbon ceramic Brembo front brake package, and ship the correct M14x1.5 lug bolts with every order. Find your fit and start enjoying your build sooner.
