Scion FR-S Wheels and Rims

Scion FR-S Aftermarket Wheel Fitment

The Scion FR-S is the rear-drive naturally-aspirated sport coupe Scion sold in the US market from 2013 through 2016, when Toyota retired the Scion brand. The car continued under the Toyota name as the Toyota 86 (2017-2020) and then the Toyota GR86 (2022 and up). All three nameplates ride on the same ZN6/ZC6 chassis that Toyota and Subaru co-developed, with Subaru building the cars in Japan. The Subaru BRZ is the same chassis with a different badge. That is why the FR-S wheel hardware reads more like a Subaru than a typical Toyota: 5x100 bolt pattern, 56.1mm hub bore, and M12x1.25 thread pitch on permanent wheel studs. Most Toyota cars run 5x114.3 with M12x1.5 thread, so a wheel set built for a Camry or a Corolla will not bolt to an FR-S. Across the FR-S lineup, our catalog supports a 17 to 19 inch diameter window and both square and staggered setups, with the staggered window biased toward a wider rear wheel. Find your FR-S below and the wheel and rim recommendations follow.

Find Your Scion FR-S

Pick your FR-S to see wheels and rims that fit. The FR-S ran a single trim across its 2013-2016 US production span on the ZN6 chassis. Bolt pattern (5x100), hub bore (56.1mm), thread pitch (M12x1.25), and the diameter and width windows are constant. Brake hardware is matched front and rear on every FR-S.

The Scion FR-S Bolt Pattern

Every Scion FR-S (2013-2016) uses a 5x100 bolt pattern with a 56.1mm hub bore. Lug count is five, thread pitch is M12x1.25 on permanent wheel studs. The same spec carries over to the successor Toyota 86 (2017-2020) and Toyota GR86 (2022 and up), and to the Subaru BRZ across both generations (ZC6 and ZD8). Toyota's standard car bolt pattern is 5x114.3 (Camry, Corolla, Highlander, RAV4, and most of the rest of the lineup), but the FR-S is built on Subaru hardware and carries Subaru spec instead. That distinction matters: wheels listed for a Camry or a Corolla at 5x114.3 / 60.1mm will NOT fit an FR-S.

Critical spec callout: the FR-S lug-nut thread pitch is M12x1.25, NOT M12x1.5. Most Toyota cars use M12x1.5. The FR-S carries the Subaru smaller pitch because the platform is Subaru-engineered. M12x1.5 lug nuts will physically thread onto an FR-S stud but the engagement will be loose and is not safe at torque. Confirm your lug nuts are M12x1.25 before mounting aftermarket wheels. Also worth noting clearly: 5x100 is NOT the same as 5x114.3. Both are 5-lug, but the bolt circle diameter is different (100mm vs 114.3mm). A 5x100 wheel will not fit a 5x114.3 hub and vice versa. Compare across the rest of the Scion lineup at our Scion wheels and rims hub.

Same Chassis as the Subaru BRZ and the Toyota 86

The Scion FR-S, the Subaru BRZ, and the Toyota 86 (and its successor the Toyota GR86) are all the same chassis. Toyota and Subaru co-developed the platform. Subaru manufactures the cars in Japan and ships them with the appropriate front badge depending on which brand is selling the car in which market. The Scion FR-S launched the platform in 2013. The car was rebadged as the Toyota 86 in 2017 when Scion was retired in the US market. It became the GR86 in 2022 alongside the 2nd generation Subaru BRZ. Across the 1st generation ZN6/ZC6 cars (FR-S 2013-2016, Toyota 86 2017-2020, Subaru BRZ 2013-2020), the wheel and brake hardware is essentially identical. If a wheel fits a 2014 Subaru BRZ, it also fits a 2014 Scion FR-S. Element catalogs the three nameplates as separate vehicle pages because customers search by car name, but the fitment math crosses cleanly.

Practical implication when cross-shopping: a wheel cataloged for the 1st generation Subaru BRZ (ZC6, 2013-2020) or the Toyota 86 (2017-2020) at the same diameter and width spec will fit the FR-S the same way. The 2nd generation BRZ (ZD8) and the Toyota GR86 (2022 and up) added a 20 inch diameter option that was not part of the 1st generation FR-S fitment window. Stick to the 17 to 19 inch range for the FR-S.

Every wheel we recommend is backed by our Fitment Guarantee. If a wheel does not fit, we pick up the wheels and refund 100 percent. No risk to you.

How We Confirm Fitment on Scion FR-S Wheels

Element Wheels measures fitment on the platforms we sell wheels for, including the FR-S across its 2013-2016 production run. For the FR-S that means clearance from the wheel to the fender, gap between the back of the wheel and the suspension, brake caliper height, hub bore confirmation (the FR-S runs 56.1mm, NOT the 60.1mm common to mainstream Toyota cars), lug-stud thread pitch confirmation (M12x1.25, NOT M12x1.5), and turning clearance with the wheel and tire installed. At our fitment facility in Chandler, Arizona, the Element Wheels team measures directly on the physical platforms we support. We don't pull specs from manufacturer sheets the way most retailers do. That measurement work is what produced the 17 to 19 inch diameter window and the square-or-staggered fitment guidance on this page.

Scion FR-S Wheels and Rims FAQ

Get Scion FR-S Wheels Right the First Time

Pick your FR-S above to see wheels and rims that fit. We measure on the ZN6 chassis directly, confirm the 5x100 / 56.1mm pattern and the M12x1.25 thread pitch on every listing, and keep the aftermarket window honest about brake clearance and turning room. Find your fit and start enjoying your build sooner.
